جدول اشتال لوله به علاوه وزن لوله های فولادی

یکی از مقاطع فولادی بسیار پرکاربرد و استراتژیک در صنعت، لوله‌ها هستند. محاسبه وزن لوله‌های فولادی و دسترسی به اطلاعات جدول اشتال لوله در کلیه محاسبات مهندسی و صنعتی مورد نیاز مهندسان است. محاسبات دقیق لوله‌ها از این جهت حائز اهمیت است که علاوه بر تأثیر مستقیم بر موارد اقتصادی بر مسائلی همچون فشار و خوردگی نیز تأثیر بسزایی دارد.



%MINIFYHTMLb466a85b12d59b980c818771fb49a2b620%

جدول وزن لوله‌ های فولادی:

معمولاً قطر لوله‌های فولادی را با واحد اینچ در جدول اشتال لوله درج می‌کنند، اما بعضاً در مصارف مهندسی ممکن است قطر لوله را با واحد میلی متر مورد استفاده قرار دهند، به همین دلیل ما در جدول وزن لوله زیر هر دو واحد را برای سهولت استفاده شما قرار داده‌ایم.

قطر لوله (inch)قطر لوله (mm)ضخامت لوله (mm)وزن هر متر (kg)وزن لوله 6 متری (kg)
1/221/310.513.06
1/221/31/250.633.78
1/221/31/50.744.44
1/221/320.975.82
1/221/32/51.217.26
1/221/331.458.7
3/426/710.663.96
3/426/71/250.794.74
3/426/71/50.965.76
3/426/721.247.44
3/426/72/51.529.12
3/426/731.8110.86
133/710.834.98
133/71/251.026.12
133/71/51.237.38
133/721.619.66
133/72/51.9411.64
133/732.3213.92
133/73/52.6816.08
133/743.0518.3
1-1/442/211.046.24
1-1/442/21/251.287.68
1-1/442/21/51.549.24
1-1/442/222.0112.06
1-1/442/22/52.4814.88
1-1/442/232.9517.7
1-1/442/23/53.4820.88
1-1/442/243.8523.1
1-1/248/311.197.14
1-1/248/31/251.488.88
1-1/248/31/51.7710.62
1-1/248/322.2913.74
1-1/248/32/52.8116.86
1-1/248/333.3820.28
1-1/248/33/53.9123.46
1-1/248/344.4226.52
260/311.498.94
260/31/251.8511.1
260/31/52.2113.26
260/322.9317.58
260/32/53.6421.84
260/334.3225.92
260/33/55.0130.06
260/345.6233.72
260/34/56.2637.56
260/356.9041.4
260/35/57.6345.78
260/368.1348.78
2-1/2761/52.7916.74
2-1/27623.7022.2
2-1/2762/54.5927.54
2-1/27635.4832.88
2-1/2763/56.3538.1
2-1/27647.2043.2
2-1/2764/58.0448.24
2-1/27658.8953.34
2-1/2765/59.8559.1
2-1/276610.5163.06
388/924.3826.28
388/92/55.4632.76
388/936.5139.06
388/93/57.5645.36
388/948.5851.48
388/94/59.5857.48
388/9510.5763.42
388/95/511.7470.44
388/9612.5175.06
4114/325.6834.08
4114/32/56.9841.88
4114/338.3850.28
4114/33/59.7658.56
4114/3411.1867.08
4114/34/512.4374.58
4114/3513.7582.5
4114/35/515.2191.26
4114/3616.2697.56
5140/32/58.6251.72
5140/3310.3662.16
5140/33/511.9571.7
5140/3413.7282.32
5140/34/515.3992.34
5140/3516.95101.7
5140/35/518.75112.5
5140/3620.51123.06
6168/32/510.4862.88
6168/3312.5875.48
6168/33/514.6988.14
6168/3416.74100.44
6168/34/518.81112.86
6168/3520.79124.74
6168/35/522.70136.2
6168/3624.84149.04
6168/36/526.35158.1
6168/3728.68172.08
8219/1316.0896.48
8219/13/518.74112.44
8219/1421.39128.34
8219/14/524.03144.18
8219/1526.65159.9
8219/15/529.27175.62
8219/1631.89191.34
8219/16/534.44206.64
8219/1737.74226.44

جدول اشتال لوله:

جدول زیر راهنمای مقادیر مشخصه در جدول اشتال لوله است.

W – section modulusG – weight
Wp – plastic section modulusA – area cross section
i – radius of gyrationAu – external surface area
Iv – torsion modulusI – moment of inertia
Wv – section modulus in torsion

اشتال لوله

D
mm
s
mm
G
kg/m
A
cm2
Au
m2/m
I
cm4
W
cm3
Wp
cm3
i
cm
Iv
cm4
Wv
cm3
355.65.648.3061.581.129431.12530.43686.0612.3818862.231060.87
355.6651.7065.901.1210070.55566.40733.3912.3620141.101132.80
355.66.354.3069.131.1210547.20593.21768.7512.3521094.411186.41
355.61085.20108.571.1216223.50912.461194.7312.2232446.991824.92
355.612102.00129.531.1219139.471076.461417.3112.1638278.942152.92
355.612.5106.00134.741.1219852.171116.551472.1212.1439704.342233.09
406.4659.3075.471.2815128.32744.50961.9914.1630256.641489.01
406.46.362.2079.191.2815849.43779.991008.5914.1531698.861559.98
406.4878.60100.131.2819873.89978.051269.9514.0939747.781956.09
406.41097.80124.531.2824475.811204.521571.6614.0248951.622409.04
406.412117.00148.691.2828937.011424.071867.1913.9557874.022848.13
406.412.5121.00154.681.2830030.661477.891940.1213.9360061.322955.77
457666.7085.011.4421618.10946.091220.4815.9543236.201892.18
4576.370.0089.201.4422654.16991.431279.8115.9445308.311982.86
457888.60112.851.4428446.361244.921612.9815.8856892.712489.83
45710110.00140.431.4435091.321535.731998.4215.8170182.633071.45
45712132.00167.761.4441556.291818.662376.8815.7483112.583637.31
45712.5137.00174.551.4443144.801888.172470.4015.7286289.593776.35
508674.3094.621.6029811.531173.681512.1017.7559623.062347.36
5086.378.0099.301.6031246.481230.181585.8117.7462492.962460.35
508898.70125.661.6039279.951546.452000.1717.6878559.913092.91
50810123.00156.451.6048520.241910.252480.3717.6197040.473820.49
50812147.00186.991.6057536.072265.202952.7717.54115072.144530.40
50812.5153.00194.581.6059755.392352.573069.6517.52119510.784705.15
559681.80104.241.7639850.851425.791834.9319.5579701.702851.58
5596.385.90109.391.7641775.841494.661924.5919.5483551.672989.33
5598109.00138.481.7652564.931880.682428.9819.48105129.873761.35
55910135.00172.471.7665001.132325.623014.3419.41130002.264651.24
55912162.00206.211.7677163.512760.773591.0819.34154327.025521.54
55912.5168.00214.611.7680161.802868.043733.9319.33160323.605736.09
6108119.00151.301.9268551.342247.582899.4021.29137102.684495.17
61010148.00188.501.9284846.552781.853600.3321.22169693.095563.71
61012177.00225.441.92100813.673305.374291.8221.15201627.356610.73
61012.5184.00234.641.92104754.713434.584463.2321.13209509.436869.16
61014.2209.00265.791.92118003.873868.985041.6421.07236007.757737.96
6608129.00163.872.0787087.932639.033401.0023.05174175.855278.06
66010160.00204.202.07107870.493268.804225.3322.98215740.986537.61
66012192.00244.292.07128267.013886.885039.4222.91256534.027773.76
66012.5200.00254.272.07133306.384039.595241.3522.90266612.778079.17
66014.2226.00288.102.07150263.044553.435923.1722.84300526.099106.85
7118139.00176.682.23109162.133070.663953.8424.86218324.266141.33
71110173.00220.232.23135301.383805.954914.3424.79270602.767611.89
71112207.00263.522.23160990.614528.575863.7924.72321981.229057.14
71112.5215.00274.302.23167343.214707.266099.4324.70334686.429414.53
71114.2244.00310.852.23188735.195309.016895.4824.64377470.3910618.01
7628149.00189.502.39134682.983534.994548.3026.66269365.957069.97
76210185.00236.252.39167028.324383.955655.3726.59334056.648767.89
76212222.00282.742.39198854.765219.296750.5826.52397709.5310438.57
76212.5231.00294.332.39206730.955426.017022.5326.50413461.9010852.02
76214.2262.00333.602.39233271.186122.607941.6626.44466542.3712245.21
8138159.00202.322.55163900.514031.995184.3728.46327801.038063.99
81310198.00252.272.55203363.865002.806448.4228.39406727.7210005.60
81312237.00301.972.55242234.535959.037699.7928.32484469.0611918.06
81312.5247.00314.362.55251860.296195.838010.6528.31503720.5812391.65
81314.2280.00356.352.55284314.846994.219061.7128.25568629.6813988.43
81316314.00400.622.55318221.667828.3310164.7128.18636443.3215656.66
91410223.00284.002.87290147.096348.958172.4931.96580294.1912697.90
91412267.00340.052.87345889.617568.709763.8231.89691779.2115137.40
91412.5278.00354.022.87359708.337871.0810159.4331.88719416.6515742.16
91414.2315.00401.412.87406344.388891.5611497.8431.82812688.7517783.12
91416354.00451.382.87455141.719959.3412903.8331.75910283.4219918.67
101610248.00316.043.19399849.587871.0510120.6935.57799699.1715742.11
101612297.00378.503.19476984.459389.4612096.7735.50953968.8918778.92
101612.5309.00394.073.19496122.959766.2012588.3035.48992245.9119532.40
101614.2351.00446.913.19560761.8611038.6214252.1235.421121523.7322077.24
101616395.00502.653.19628479.2512371.6416001.3735.361256958.5024743.28
121910298.00379.823.83694014.2811386.6214617.1442.751388028.5722773.23
121912357.00455.033.83828716.1013596.6517482.7642.681657432.2027193.31
121912.5372.00473.793.83862180.9114145.7118196.1842.661724361.8228291.42
121914.2422.00537.473.83975333.9516002.2020612.8742.601950667.9032004.40
121916475.00604.693.831094091.0817950.6323156.7142.542188182.1635901.27

اگر از جدول اشتال لوله موجود در این صفحه استفاده نموده اید و سوالی یا مشکلی در رابطه با آن برایتان وجود داشت ، آن را از بخش نظرات همین مطلب با ما در میان بگذارید.

منبع جدول اشتال
